174
Effect/Parameter List
79: VR CHORUS
This chorus is a descendant of the Roland VR Series effects.
80: VR TREMOLO
This tremolo is a descendant of the Roland VR Series effects.
This changes the volume level in a cyclic manner.
Switching between the Mono and Stereo Tremolo Type
settings also switches the volume control waveform.
81: VR AUTO WAH
This wah is a descendant of the Roland VR Series effects. This
is a special wah effect (an effect in which the tone is changed
cyclically) produced by shifting the filter in a cyclic fashion.
You can switch the Control Type parameter to select from Auto
Wah, Touch Wah, or Pedal Wah.
Settings when using a pedal wah with a pedal connected to FC1
• MFX Control: Manual
• Control Type: PEDAL
• EDIT/ 2. Control/ FC1: MFX Control
82: VR PHASER
This phaser is a descendant of the Roland VR Series effects.
This creates a swirling effect by adding sounds that are out of
phase with the original sound.
83: ORGAN MULTI
This is an effect combining the VK series internal effect with an
organ effect with the same features.
It comprises vibrato/chorus, overdrive, and rotary effects.
Assignable Parameters
MFX Control
Depth, Rate, Balance
Parameter Value Description
Pre Delay 0.0–100 ms
Amount of time that it is to take for the
chorus sound to be produced after the
original sound has sounded.
Rate Mode Hz, Note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Modulation rate (Hz)
Rate ( ) note (*1) Modulation rate (note)
Depth 0–127 Modulation Depth
Phase 0–180 deg Amount of breadth in the chorus sound
Balance
D100:0W–
D0:100W
Volume balance between the original,
dry sound (D) and the chorus sound
(W)
Level 0–127 Output volume
Assignable Parameters
MFX Control
Rate, Depth, Tremolo Type
Parameter Value Description
Tremolo Type Mono, Stereo
Mono:
The left and right volume levels
change simultaneously.
Stereo:
The left and right volume levels
change in alternating fashion.
Rate Mode Hz, Note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz
Frequency at which the effect is
applied (Hz)
Rate ( ) note (*1)
Frequency at which the effect is
applied (note)
Depth 0–127 Depth of the effect
Low Gain -15–+15 dB Boost or cut in the low end
High Gain -15–+15 dB Boost or cut in the high end
Level 0–127 Output volume
Assignable Parameters
MFX Control Rate, Depth, Peak, Manual
Parameter Value Description
Control Type
MOD, TOUCH,
PEDAL
Effect Control Types
MOD:
The tone changes at the set rate.
TOUCH:
The tone changes in response
to changes in the volume.
PEDAL:
The tone changes according to
the function of the Manual parameter.
Can be used as a pedal wah.
Filter Type
LPF, BPF
Filter Type
LPF:
Produces a wah effect over a
wide frequency range.
BPF:
Produces a wah effect over a
narrow frequency range.
Manual 0–127
When Control Type is set to “PEDAL,”
you can use this parameter to change
the tone.
Peak 0–100
Wah effect bandwidth
The bandwidth narrows as the value is
increased.
Rate Mode Hz, Note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Wah effect rate
Rate ( ) note (*1)
Wah effect rate (note)
When Control Type is set to
“TOUCH,” this adjusts the sensitivity to
the volume used in changing the tone.
Depth 0–127 Depth of the wah effect’s sweep
Phase 0–180 deg
Ratio of the wah effect sound in the left
and right sides when the spread is not
distributed evenly
Low Gain -15–+15 dB Boost or cut in the low end
High Gain -15–+15 dB Boost or cut in the high end
Level 0–127 Output volume
Assignable Parameters
MFX Control
Rate, Resonance, Depth
Parameter
Value Description
Rate Mode
Hz, Note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Phaser Frequency (Hz)
Rate ( ) note (*1) Phaser Frequency (note)
Depth 0–127 Depth
Resonance 0–127 Feedback Level
Step Sw OFF, ON
Setting this to ON creates a step
phaser.
Step Rate Mode Hz, Note
When this is set to “note,” the effect is
synchronized with the tempo.
StepRate(Hz) 0.10–20.00 Hz
Rate of stepped changes in phaser
effect (Hz)
Step Rate ( ) note (*1)
Rate of stepped changes in phaser
effect (note)
Low Gain -15–+15 dB Boost or cut in the low end
High Gain -15–+15 dB Boost or cut in the high end
Level 0–127 Output volume
Assignable Parameters
MFX Control Rotary Speed, OD Drive
Parameter Value Description
RD-700GX_e.book 174 ページ ２００８年２月１３日 水曜日 午後５時４９分
