(1) Actuator pin
(2) Actuator device for actuator pin
Installation steps
1. Use the actuator pin (1) to secure the drive in the actuator device (2).
Make sure that the actuator pin engages in the pre-installed actuator device in the
shaft.
Caution! The plastic discs, actuator and bearing rings are already pre-installed with
screws. The drive does not need to be screwed together with the winding shaft. No
transport lock needs to be removed.
