Page | 49
PROGRAMMING FOR THE RADIO RECEIVER/HANDHELD
TRANSMITTER
Several handheld transmitters (256) can be taught in for the same system. All handheld
transmitters must be taught in on the receiver board. This ensures that the handheld
transmitter(s) only respond to your receiver.
(1) LED (red) – illuminated during use
(2) ‘AUF’ (OPEN) operating switch
(3) ‘Licht’ (Light) operating switch (optional)
(4) ‘STOP’ operating switch
(5) ‘ZU’ (CLOSED) operating switch
Caution! Always perform a ‘RESET’ before the initial start-up!
