Rollo Solar RT 200 - Distribution Box Preparation; Grounding and Connection Prep

Page | 10
PREPARING THE DISTRIBUTION BOX
(1) Grounding
(2) Connecting piece with internal cable gland (2 pieces)
(3) Screw-type blank cap (optional additional connecting piece with cable gland)
Installation steps
1. Install the connecting pieces with internal cable gland (2)
2. Install the screw-type blank cap (3) or, if necessary, a third connecting piece
(optionally available)
1
2
2
3
