TRANSFORMER AND MOTOR FUSE
Caution! Electrical connection work may only be carried out by a qualified, skilled
electrician! Switch off the power supply to the control board during all electrical work!
1. LED (green) / power light – 24 volt circuit
2. LED (green) / mains switch / power light – 230 volt
3. Transformer with motor fuse
4. Transformer mains plug
5. Controller
6. Motor fuse (enlarged – fuse rating may differ)
