INSTALLING THE FLEXIBLE TUBE ON THE PRE-ASSEMBLY
FLANGE
(1) Flexible tube (green or transparent)
(2) Tube clamp
(3) Pre-assembly flange (outside of pool)
Caution! Only install the flexible tube (1) on the pre-assembly flange when it is cool (3). If
the pre-assembly flange has been welded on in the case of stainless steel pools, for
example, it may still be hot and could damage the flexible tube (1)!
Installation steps
1. Make sure that the tube clamp (2) is on the flexible tube (1). Then slide the flexible
tube (1) over the pre-assembly flange (3).
2. Tighten the tube clamp (2) with a VA Phillips screwdriver.
