Rollo Solar RT 200 - Installing the RT 200 Motor

Page | 2
INSTALLING THE RT 200 IN THE SHAFT
(1) Bearing ring
(2) Motor with actuator pin
(3) Actuator device for actuator pin
The plastic disc, actuator and bearing ring are screwed to the shaft. The plastic discs are
pre-installed in the shaft.
