Rollo Solar RT 200 - Status Indicators and Buttons; LED Indicator Meanings; Operating Button Functions

Page | 33
STATUS INDICATORS AND OPERATING BUTTONS
(1) ‘AUF’ (OPEN) LED
(2) LED ‘PROG’
(3) LED ‘CLOSED’
(4) DIP switches
(5) Internal programming/operating buttons
AUF/PROG/ZU (OPEN/PROG/ZU)
1 2 3
5
4
