Rollo Solar RT 200 - Page 45

Page | 35
RSC 3
RSC 4
LED
LED colour
LED
LED colour
AUF (OPEN)
Red
AUF (OPEN)
Yellow
PRG
Yellow
PRG
Red
CLOSED (ZU)
Green
CLOSED (ZU)
Green
LED
BLINKING
ILLUMINATED
STATUS
Error message
AUF (OPEN)
CLOSED
Illuminated
Controller not programmed
AUF (OPEN)
CLOSED
Blinking
Emergency mode active
PROG
AUF (OPEN)
Blinking
Error – motor/pulse generator fault
PROG
ZU (CLOSED)
Blinking
Error – thermoprotector active
AUF (OPEN)
PROG
ZU (CLOSED)
Blinking
Error – undervoltage
AUF (OPEN)
Illuminated
‘AUF’ (OPEN) end position reached
AUF (OPEN)
Blinking
Cover is moving in ‘AUF’ (OPEN) direction
ZU (CLOSED)
Illuminated
‘CLOSED’ end position reached
ZU (CLOSED)
Blinking
Cover is moving in ‘CLOSED’ direction
Please refer to the section ‘Course of action for errors’ if error messages are displayed
