Rosemount 3095FB - Installation Procedures

Reference Manual
00809-0100-4738, Rev DA
May 2006
2-3
Rosemount 3095FB
INSTALLATION
PROCEDURES
Figure 2-1 details the full procedure for installing a new 3095FB.
Figure 2-1. Rosemount 3095FB Installation Flowchart
A
B
B
START
A
B
Unpack the
Rosemount
3095FB
Review the
3095FB Product
Manual
Bench
Configure
?
BENCH
CONFIGURE
Connect Bench
Power Supply
Connect Personal
Computer
Perform Bench
Configuration
Tasks
(Optl.) Perform
Bench Calibration
Tasks
FIELD
INSTALLATION
Review Installation
Considerations
Mount
Transmitter and
Install Bolts
(Optional) Install
RTD Assembly
Make Field Wiring
Connections
DONE
Yes
No
(Optl.) Perform
Field Calibration
Tasks
Bench
Configuration
Performed
?
No
Perform
Configuration
Tasks
Yes
Review Appendix B
Hazardous
Location
?
Yes
No
