Appendix C: Modbus Mapping of 32-bit Floating Point Registers
32-bit Floating Point Registers
Modbus Access
DESCRIPTION
Address
Address
Type
Attributes
Functional
Area
Data / Control
7401 FP register RO PVs DP
7402 FP register RO SP
7403 FP register RO PT
7404 FP register RO Diagnos-
tics
Status Bytes
7405 FP register RO Status Bytes
7406 FP register RO Status Bytes
7407 FP register RO Sensor lim-
its
DP upper range limit
7408 FP register RO DP lower range limit
7409 FP register R/W, WP DP upper operating limit
7410 FP register R/W, WP DP lower operating limit
7411 FP register RO SP upper range limit
7412 FP register RO SP lower range limit
7413 FP register R/W, WP SP upper operating limit
7414 FP register R/W, WP SP lower operating limit
7415 FP register RO PT upper range limit
7416 FP register RO PT lower range limit
7417 FP register R/W, WP PT upper operating limit
7418 FP register R/W, WP PT lower operating limit
7419 FP register R/W, WP DP calibra-
tion
DP offset
7420 FP register R/W, WP DP slope
7421 FP register R/W, WP DP damping
