4.3 Identify Transmitter
Table 4-2 Identify Transmitter
Modbus Access
DESCRIPTION
Address
Address
Type
Attributes
Functional
Area
Data / Control
0001 Input reg-
ister
RO identify
transmitter
Manufacturer’s Code (U8)
38 Rosemount
0002 Input reg-
ister
RO Transmitter Type Code (U8)
31 3095FB Multivariable Trans-
mitter with Modbus Protocol
0003 Input reg-
ister
RO Output Board Software Rev Level
(U8 + U8)
MSB = integer part
LSB = decimal part
i.e. 0x6803 = rev. 104.3
0004 Input reg-
ister
RO Sensor Module Software Rev
Level (U8)
0005,
0006
Input reg-
ister
RO Sensor Module Serial Number
(U24)
0007,
0008
Input reg-
ister
RO Transmitter Serial Number (U24)
0009 Input reg-
ister
RO Hardware Rev Level (U8)
0010 Input reg-
ister
RO Modbus Specific Rev Level (U8)
0011 Input reg-
ister
RO Sensor Type (U8)
%xxxx xxx1 absolute SP
%xxxx xxx0 gage SP
