Reference Manual
00809-0100-4738, Rev DA
May 2006
Rosemount 3095FB
B-2
Canadian Standards Association (CSA) - U.S. and Canada
M 3095FC
Explosion-Proof for Class I, Division 1, Groups C and D including optional solar panel: mast
option: Suitable for use in Class I, Division 2, Groups A, B, C, D, and T3. CSA Enclosure
Type 4.
European Certifications H ATEX Flameproof
3095FB
Certificate Number: KEMA02ATEX2320X II 1/2 G
EEx d IIC T5 (-50°C ≤ T
amb
≤ 80°C)
T6 (-50°C ≤ T
amb
≤ 65°C)
V
max
= 55V dc
1180
Special Conditions for Safe Use (x):
The device contains a thin wall diaphragm. Installation, maintenance, and use shall take
into account the environmental conditions to which the diaphragm will be subjected. The
manufacturer’s instructions for installation and maintenance shall be followed in detail to
assure safety during its expected lifetime.
3095FC
Certificate Number: LCIE05ATEX6057X II 2 G
EEx d IIB T5
V
max
= 28V dc
IP66
1180
Special Conditions for Safe Use (x):
Operating ambient temperature: -40°C to 75°C
The users have to make sure that the thermal fluid transfer doesn’t overheat the equipment
to a temperature corresponding to the spontaneous combustion temperature of
surrounding gas.
P ATEX Dust
3095FB
Certificate Number: KEMA02ATEX2321 II 1 D T90°C Ambient Temp (-50°C ≤ T
amb
≤
80°C)
V = 55 Vdc MAX
I = 23 mA MAX
IP66
1180
