Reference Manual
00809-0100-4738, Rev DA
May 2006
Rosemount 3095FB
A-2
User Interface Software and Hardware Requirements:
• IBM-compatible PC
• 10 MB of available hard drive space
• Microsoft
®
Windows
®
98 or higher operating system
• CD-ROM drive
• 32 MB of RAM
Temperature Limits
Process (at transmitter isolator flange for atmospheric pressures and above):
• –40 to 250 °F (–40 to 121 °C)
• Inert fill sensor: 0 to 185 °F (-18 to 85 °C).
• Process temperatures above 185 °F (85 °C) requires derating the ambient limits by a
1.5:1 ratio.
Ambient:
• –40 to 185 °F (–40 to 85 °C)
• with integral meter: -4 to 175 °F (-20 to 75 °C)
Storage:
• –50 to 212 °F (–46 to 100 °C)
• with integral meter: -40 to 185 °F (-40 to 85 °C)
Turn-on Time
Process variables will be within specifications less than 4 seconds after power is applied to
transmitter.
Damping (3095FB only)
Response to step input change can be user-selectable from 0.1 to 30 seconds for one time
constant. This is in addition to sensor response time of 0.2 seconds.
PERFORMANCE
SPECIFICATIONS
(Zero-based spans, reference conditions, silicone oil fill, 316 SST isolating
diaphragms, and digital trim values to the span end points)
Specification Conformance
The Rosemount 3095FB maintains a specification conformance of measured
variables to at least 3 .
Differential Pressure Range 2
• 0–2.5 to 0–250 inH
2
O (0–6,2 to 0–622,7 mbar)
(100:1 rangeability is allowed)
Range 3
• 0–10 to 0–1000 inH
2
O(0–0,0249 to 0–2,49 bar)
(100:1 rangeability is allowed)
Accuracy (including Linearity, Hysteresis, Repeatability)
Range 2-3: 3095FB Ultra for Flow (Option U3)
(1)
• ±0.05% DP reading for rangedown from 1:1 to 3:1 of URL
• For rangedown greater than 3:1 of URL
• Accuracy =
Range 2-3:
• ±0.075% of span for spans from 1:1 to 10:1 URL
• For spans less than 10:1 rangedown
σ
(1) Ultra for Flow (Option U3) applicable for DP ranges 2 and 3 with SST isolator material and silicone fill fluid
only.
0.05 0.0145
URL
Reading
-------------------------
⎝⎠
⎛⎞
+
±
% Reading
Accuracy 0.025 0.005
URL
Span
--------------
⎝⎠
⎛⎞
+%ofspan=
