Reference Manual
00809-0100-4738, Rev DA
May 2006
Rosemount 3095FB
A-4
Ambient Temperature Effects per 50 °F (28 °C)
• ±0.72 °F (0.40 °C) for process temperatures from
–40 to 185 °F (–40 to 85°C)
• (±1.28 °F (0.72 °C) + 0.16% of reading) for process temperatures from 185 to 1200 °F (85 to
649 °C)
Stability
±1.0 °F (0.56 °C) for one year
PHYSICAL
SPECIFICATIONS
Electrical Connections
• ½–14 NPT, M20 x 1.5 (CM20), PG-13.5
RTD Process Temperature Input:
100-ohm platinum RTD per IEC-751 Class B
Process Connections
• Transmitter: ¼–18 NPT on 2
1
/8-in. centers
• RTD: RTD dependent (see ordering information)
Radiated/Conducted Transmissions
Meets requirements of IEC 61326
Process Wetted Parts
Isolating Diaphragms
• 316L SST or Hastelloy C-276
®
Drain/Vent Valves
• 316 SST or Hastelloy C
®
Flanges
• Plated carbon steel, 316 SST, or Hastelloy C
Wetted O-rings
• Glass-Filled TFE
Non-Wetted Parts
Electronics Housing
• Low copper aluminum
Bolts
• Plated carbon steel per ASTM A449, Grade 5; or austenitic 316 SST
Fill Fluid
• Silicone oil
• Inert oil (available for gage pressure ranges only)
Paint
• Polyurethane
O-rings
• Buna-N
Weight
Components
Weight in lb. (kg)
3095FB
3095 Transmitter
6.0 (2.7)
LCD Meter
0.5 (0.2)
SST Mounting Bracket
1.0 (0.5)
12 ft. (3.66 m) RTD Shielded Cable
0.5 (0.2)
12 ft. (3.66 m) RTD Armored Cable
1.1 (0.5)
24 ft. (7.32 m) RTD Shielded Cable
1.0 (0.5)
24 ft. (7.32 m) RTD Armored Cable
2.2 (1.0)
Battery / Solar panel
–
Battery Backup
–
