Rosemount 3095FB - RTD Assembly (Optional); RTD Installation Procedure

Reference Manual
00809-0100-4738, Rev DA
May 2006
Rosemount 3095FB
2-13
Figure 2-5. Output Board Switches
RTD Assembly (Optional) The Rosemount 3095FB MultiVariable Transmitter is compatible with the
Series 68 or Series 78 RTD Assembly.
NOTE
To meet ISSep/CENELEC Flameproof certification, only European
Flameproof Cable Assemblies (Process Temperature Input Codes A, B, or C)
may be used for RTD cable installation.
RTD Installation Procedure
All RTD Cable Assemblies use the 3095 RTD Cable Connector.
OUTPUT ELECTRONICS BOARD
OFF
ON
Real-Time
Clock
Battery
Jumper
<
<
SECURITY
>
>
ON
OFF
Baud
Rate
S1 S2
ON
OFF
RS-485
Configuration
AC (B) (A)
ON
OFF
3095-065AB
