Reference Manual
00809-0100-4738, Rev DA
May 2006
Rosemount 3095FB
A-8
Code Terminal Block
A
Standard •—
B
With Integral Transient Protection • •
C
CE MARK/ Compliant with EMC - Transient Protection Included • —
Code Display
0
None • •
1
LCD Display • •
Code Bracket
0
None (required for option code S3 or S5) ••
1
Coplanar SST Flange Bracket for 2-in. Pipe or Panel Mount, SST Bolts • •
2
Traditional Flange Bracket for 2-in. Pipe Mounting, CS Bolts • •
3
Traditional Flange Bracket for Panel Mounting, CS Bolts • •
4
Traditional Flange Flat Bracket for 2-in. Pipe Mounting, CS Bolts • •
5
Traditional Flange Bracket for 2-in. Pipe Mounting, 300 Series, SST Bolts • •
6
Traditional Flange Bracket for Panel Mounting, 300 Series, SST Bolts • •
7
Traditional Flange Flat Bracket for 2-in. Pipe Mounting, 300 Series, SST Bolts • •
8
SST Traditional Flange Bracket for 2-in. Pipe Mounting, 300 Series, SST Bolts • •
9
SST Traditional Flange Flat Bracket for 2-in. Pipe Mounting, 300 Series, SST Bolts • •
Code Bolts
0
CS bolts • •
1
Austenitic 316 SST bolts • •
N
None (required for Options code S5) • •
Code Product Certifications
0
None • •
A
FM Approvals Explosion-Proof • —
C
Canadian Standards Associate (CSA) Explosion Proof • —
H
ATEX Flame-proof • —
M
Canadian Standards Association (CSA) US and Canada Explosion-Proof — •
P
ATEX Dust • —
Code Engineered Measurement Solution (EMS)
N
Process Variable Measurement: MODBUS • —
C
Mass Flow with Process Variable Measurement and Data Logging: MODBUS (required for 3095FC) — •
Code Options
Performance Class
U3
(2)
Ultra for Flow: ±0.05% DP reading accuracy, up to 100:1 rangedown, 10 year stability, limited 12 year warranty • —
S3 Assembly with 405 Compact Orifice (requires compact orifice model number, see 00813-0100-4810) • —
S4
(3)
Assembly with Annubar Averaging Pitot Tubes or 1195 Integral Orifice Plates
(requires corresponding model number, see 00813-0100-4809, 00813-0100-4760, or 00813-0100-4686)
•—
S5
Assemble to 305 Integral Manifold (requires integral manifold model number) • •
C1
Custom Flow Configuration (requires completed Configuration Data Sheet) • •
A3
Mast with Solar Panel Assembly and 12 Vdc Batteries — •
P1
Hydrostatic testing with certificate ••
P2
Cleaning for Special Services • •
Q4
Calibration Certificate ••
Q8
Material Traceability Certification per EN 10204 3.1B • •
DF
(4)
1
/2–14 NPT Flange Adapter, Carbon Steel, Stainless Steel, Hastelloy C • •
A1
Additional RS-232 Communication Board — •
A2
12 Vdc System with Batteries —•
Typical Model Number:3095FB23ABA11AB010AN
(1) Materials of Construction comply with metallurgical requirements highlighted within NACE MR0175/ISO 15156 for sour oil field production environments.
Environmental limits apply to certain materials. Consult latest standard for details. Selected materials also conform to NACE MR0103 for sour refining
environments.
(2) Ultra for Flow (Option U3) applicable for DP ranges 2 and 3 with SST isolator material and silicone fill fluid only.
(3) With a primary element installed, the maximum operating pressure will be the lesser of either the transmitter or the primary element.
(4) Material determined by Flange Style material selection (Not available with S4 option).
• Available
— Not available
3095FB 3095FC
