Reference Manual
00809-0100-4738, Rev DA
May 2006
Rosemount 3095FB
A-10
Spares
Category
(1)
Item
No.
Flanges Parts Description Part Number
A11Process Flanges
Differential Coplanar Flange SST, 7/16 m 03031-1350-0022
Nickel-Plated Carbon
Steel
03031-0388-0025
316L SST 03031-0388-0022
Hastelloy C 03031-0388-0023
Coplanar
™
Flange Alignment Screw (package of 12 screws) 03031-0309-0001
Differential Traditional Flange
DIN compliant Traditional Flange, SST, 7/16 in Adaptor/Manifold Bolting 03031-1350-0012
Spares
Category
(1)
Item
No.
Flange Adapter Union Parts Description Part Number
B 13 Nickel-plated Carbon Steel 02024-0069-0005
316L SST 02024-0069-0002
Hastelloy C 02024-0069-0003
Spares
Category
(1)
Item
No.
Drain/Vent Valve Kits Parts Description Part Number
A 10 Vent Valve Kits 316L SST Valve Stem and
Seat Kit
01151-0028-0022
Hastelloy C Valve Stem
and Seat Kit
01151-0028-0023
(Each kit contains parts for one transmitter.)
Spares
Category
(1)
Item
No.
O-Ring Packages Parts Description Part Number
B 2 Electronic Housing, Cover (Standard and Meter) 03031-0232-0001
B 8 Electronics Housing, Module 03031-0233-0001
B 15 Process Flange, Glass-filled Teflon 03031-0234-0001
B 14 Flange Adapter, Glass-filled Teflon (Each package contains 12 O-rings.) 03031-0242-0001
Spares
Category
(1)
Item
No.
Mounting Brackets Parts Description Part Number
Mounting Flange Bracket Kits (Figure 2)
B Coplanar Flange Bracket Kit for 2 in. Pipe or Panel Mounting, all SST 03031-0189-0003
B Traditional flange Bracket Kit for 2 in. Pipe Mounting, CS Bolts 03031-0313-0001
Spares
Category
(1)
Item
No.
Bolt Kits Parts Description Part Number
B Coplanar Flange
Flange Bolt Kit Carbon Steel (set of 4) 03031-0312-0001
316 SST (set of 4) 03031-0312-0002
Flange/Adapter Bolt Kit Carbon Steel (set of 4) 03031-0306-0001
316 SST (set of 4) 03031-0306-0002
Manifold/Flange Kit Carbon Steel (set of 4) 03031-0311-0001
316 SST (set of 4) (Each
kit contains bolts for one
transmitter)
03031-0311-0002
Manifold
Carbon Steel
316 SST
