Model 3095FB Multivariable Transmitter with Modbus Protocol
Modbus Protocol Guide
Page 37 of 79
Table 5-7 PV Scaled Integer Y Value
Modbus Access
DESCRIPTION
Address
Address
Type
Attributes
Functional
Area
Data / Control
0188 Holding
register
RW PV Scaled
Integers
DP_y1
0189 Holding
register
RW DP_y2
0190 Holding
register
RW SP_y1
0191 Holding
register
RW SP_y2
0192 Holding
register
RW PT_y1
0193 Holding
register
RW PT_y2
*Attributes: R/W = Read/Write, RO = Read Only, WP = Write Protected
**These registers are available at multiple Modbus addresses (see Section 2.3 located in
the Modbus Protocol Guide)
