Model 3095FB Multivariable Transmitter with Modbus Protocol
Modbus Protocol Guide
Page 51 of 79
0058 0119
(cont)
0407
(cont)
7 AD DP signal below Lower Range Limit - 10%
0059 6 AD SP signal above Upper Range Limit + 10%
0060 5 W SP signal above Upper Range Limit
0061 4 SP signal above Upper Operating Limit
0062 3 SP signal below Lower Operating Limit
0063 2 W SP signal below Lower Range Limit
0064 1 AD SP signal below Lower Range Limit - 10%
0065 0 AD SP sensor shorted
0066 0120 0408 15 AD SP signal is unreasonable - open bridge
0067 14 AD PT signal above Upper Range Limit + 10%
0068 13 W PT signal above Upper Range Limit
0069 12 PT signal above Upper Operating Limit
0070 11 PT signal below Lower Operating Limit
0071 10 W PT signal below Lower Range Limit
0072 9 AD PT signal below Lower Range Limit - 10%
0073 8 AD RTD is disconnected
0074 7 AD ST signal is above Upper Internal Limit
0075 6 AD ST signal is below Lower Internal Limit
Not Available as Discrete
Inputs
5 Reserved
4 Reserved
3 Reserved
2 Reserved
1 Reserved
0 Reserved
0121 0409 15 AD Sensor module is NOT updating
Table 8-1 Mapping of Status Bits to Coils, Input Registers, and Floating Point Registers
Discrete
Input
Address
Input
Register
Address
Floating
Point
Register
Address
Bit
Position Attributes
Description
