Rosemount 3095FB - Page 91

Model 3095FB Multivariable Transmitter with Modbus Protocol
Modbus Protocol Guide
Page 60 of 79
0443,
0444
FP register R/W, WP SP calibra-
tion
SP offset
0445,
0446
FP register R/W, WP SP slope
0447,
0448
FP register R/W, WP SP damping
0449,
0450
FP register R/W, WP PT calibra-
tion
PT offset
0451,
0452
FP register R/W, WP PT slope
0453,
0454
FP register R/W, WP PT damping
0455,
0456
FP register R/W, WP User
Entered PT
User Entered PT Value
0457,
0458
FP register RO PVs ST
0469,
0470
FP register RW PV Scaled
Integers
DP_x1
0471,
0472
FP register RW DP_x2
0473,
0474
FP register RW SP_x1
0475,
0476
FP register RW SP_x2
0477,
0478
FP register RW PT_x1
0479,
0480
FP register RW PT_x2
*Attributes: R/W = Read/Write, RO = Read Only, WP = Write Protected
**These registers are available at multiple Modbus addresses (see Section 2.3)
Floating Point Register Pairs
Modbus Access
DESCRIPTION
Address
Address
Type
Attributes
Functional
Area
Data / Control
