Rosemount 3152 - Rosemount 3150 Series Installation Guide; Installation Overview and Safety

Reference Manual
00809-0100-4835 Rev BD
July 2016
Rosemount 3150 Series
SECTION 2: INSTALLATION
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . .
Mechanical Considerations. . . . . . . . . . . . . . . . . . . . . . . .
Electrical Considerations . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . .
page 2-1
page 2-1
page 2-2
page 2-2
page 2-7
page 2-10
SAFETY MESSAGES
Procedures and instructions in this section may require special
precautions to ensure the safety of the personnel performing the
operation. Refer to the following safety messages before performing
an operation preceded by this symbol .
Warnings
WARNING
Explosions can result in death or injury.
• Do not remove the transmitter covers in explosive
environments when the circuit is live.
• Verify that the operating atmosphere of the transmitter is
consistent with the appropriate qualification parameters.
OVERVIEW
This section contains the following installation considerations:
• General Considerations
• Mechanical Considerations
o Process Connections
o Impulse Piping
o Mounting Configurations
o Conduit
o Electrical Housing
• Electrical Considerations
• Installation Procedures
o Mechanical
o Electrical
