Reference Manual
00809-0100-4835 Rev BD
July 2016
Rosemount 3150 Series
3-4
Damping Adjustment
(optional)
Coarse Zero
Select Jumper
Figure 3-1 – Zero and Span
Figure 3-2 – Electronics Assembly
Electronics
Assembly located
inside electronics
housing
Zero and Span
Adjustment Screws
