Rosemount 3152 - Page 5

Reference Manual
00809-0100-4835 Rev BD
July 2016
Rosemount 3150 Series
iii
Revision Status
Changes from March 2015 (Rev BC) to July 2016 (Rev BD)
Page
(Rev BC)
Page
(Rev BD)
Changes
Cover,
throughout
Cover,
throughout
Document revision change from March 2015 to July 2016, Rev BC to Rev BD
Throughout
Throughout
Updated references and terminology for consistency throughout document.
3-11 3-11
Minimum time constant for damping adjustment set to maximum position for
3153 and 3154 transmitters (output code T) changed from 0.8 sec to 1.2 sec.
5-11 & 5-13 5-11 & 5-14
Relocated step 2 in the Preliminary Electrical Housing Reassembly Section to
the Electronics Housing Cover Installation Section and revised for clarity.
5-12 5-12
Updated Electronics Assembly Installation procedure to include additional
instruction for installing the connector plug.
5-12 to 5-18 5-12 to 5-19
Added Figure 5-7 – Connector Plug Detail and updated subsequent figure and
page numbers accordingly.
NOTE
The above Revision Status list summarizes the changes made. Please refer to both manuals for complete
comparison details.
