Rosemount 3152 - Transmitter Spare Parts List

Rosemount 3150 Series
Reference Manual
00809-0100-4835 Rev BD
July 2016
6-4
Spare Parts Category
(1)
Quantity Required
(2)
Item Number
(3)
Rosemount Order
Number
Part Description
Transmitter: Electronics
-
3152N Electronics Assembly, Output Code A
4
1
A
03154-5020-0002
3152N Electronics Assembly, Output Code B
4
1
A
03154-5020-0001
3153N Electronics Assembly, Output Code R
4
1
A
03154-5020-0004
3153N Electronics Assembly, Output Code T
4
1
A
03154-5020-0003
3154N Electronics Assembly, Output Code R
4
1
A
03154-5020-0004
3154N Electronics Assembly, Output Code T
4
1
A
03154-5020-0003
3152K Electronics Assembly, Output Code A
4
1
A
03154-5020-0008
3152K Electronics Assembly, Output Code B
4
1
A
03154-5020-0007
3154K Electronics Assembly, Output Code R
4
1
A
03154-5020-0006
3154K Electronics Assembly, Output Code T
4
1
A
03154-5020-0005
Transmitter: Terminal Blocks
-
Terminal Block, Standard, ALL MODELS
6
1
B
03154-5021-0001
Terminal Block, Transient Protection
(4)
6
1
B
03154-5021-0002
Electronics Housing: Covers & Accessories
-
Electronics Housing Cover, AL, 3152/3153
1
2
03154-5024-0001
Electronics Housing Cover, SST, 3152
1
2
03154-5024-0002
Electronics Housing Cover, SST, 3154
1
2
03154-5024-0003
1/2" NPT Conduit Plug, 316L SST
1
03153-5020-0001
M20 Conduit Plug, 316L SST
1
03153-5025-0001
NPT conduit Elbow w/Tube Adapter, SST, Female
1
03152-0702-0001
Process Flange Accessories
-
3150 Drain/Vent Valves (Qty=2 each)
2
03154-5015-0001
Drain/Vent Valve Stem
2
A
03154-5015-0002
Metal C-Ring (Qty=1)
9
03154-5016-0001
Process Connection Plug, 1/4" NPT, SST (Qty=1)
03154-5017-0001
Process Connection Plug, 1/4" NPT, SST (Qty=2)
03154-5017-0002
Screen Plug (Qty=1)
03154-5018-0001
Flange Bolt Kit, Standard
11,13
1
03154-5019-0001
Flange Bolt Kit, P9 Option
11,13
1
03154-5019-0002
O-Ring Kits
-
Electronics Housing Cover O-ring Kit (Qty=2)
2
1
C
03154-5001-0002
Electronics Housing Cover O-ring Kit (Qty=1)
2
2
C
03154-5001-0003
Lubricants
-
Molykote
®
55 O-ring Lubricant (0.25 oz)
03154-5002-0001
Molykote
®
55 O-ring Lubricant (5.3 oz)
03154-5002-0002
Lubri-Bond A Cover Lubricant (12 oz)
03154-5003-0001
Continued on Next Page
TRANSMITTER SPARE PARTS
LIST
Spare parts list for Rosemount 3152, 3153 and 3154 model
transmitters.
