Technical Specifications
AYC-E/Q60 Series Installation and Programming Manual 11
2. Technical Specifications
Electrical Characteristics
Power Supply Type
Linear (recommended)
Operating Voltage Range
E/T: 6–16 VDC
Q: 5–16 VDC
(when used as a controller, provided by
the secured intelligent power supply)
Input Current Standby (12 VDC)
110 mA
Input Current Max (16 VDC)
130 mA
LED Control Input
Dry contact N.O.
Tamper Output
Open collector, active low, 32 mA max
sink current
Cable Distance to Host
Controller
Up to 150 m (500 ft) using an 18-AWG
cable
Max. Proximity Card Read
Range*
Rosslare proximity: E – 40 mm (1.57 in.), Q
– 45 mm (1.77 in.), T – 40 mm (1.57 in.)
HID Prox: E – 40 mm (1.6 in.), Q – 45 mm
(1.8 in.), T – 30 mm (1.2 in.)
Proximity Card Modulation
Rosslare proximity/HID Prox at 125 kHz
Proximity Card Compatibility
Rosslare proximity/HID Prox cards
Card Transmit Format (Reader)
Rosslare proximity cards: Wiegand 26-bit,
or Clock & Data
HID cards: According to card type
Keypad Transmit Format
(Reader)
Programmable PIN code formats
LED Indicators
Two tri-colored LEDs
Communication
Data1/C1, Data0/C2–open collector,
5 V termination
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.
