Controller Operation
34 AYC-E/Q60 Series Installation and Programming Manual
5. Controller Operation
The AYC-E/Q60 series can function both as a reader and as a
controller. If the unit is connected to a Rosslare secured intelligent
power supply, it functions as a controller indicated by two beeps
immediately after power-on reset.
The Lock Strike Output and REX input are not located on the unit,
eliminating the possibility of unauthorized entry to the restricted area.
5.1 Normal, Secure, and Master Users
The units accept up to 500 users and provide entry via the use of PIN
codes and/or proximity cards. Each user is provided with two code
memory slots: Memory Slot 1 (Primary code) and Memory Slot 2
(Secondary code).
The PIN code length has several options. The PIN code length can be a
set number of 4, 5 or 6 digits or it can be a 4–8 digits option. When
choosing the 4–8 digit option, please note that you should either
enter zeros before the code, or press # at the end (for example if your
code is 12345, enter either 00012345 or 12345#).
Entering a code refers to either PIN or card depending on the
model you have.
The way in which the two memory slots are programmed determines
a user’s access level and also determines the way in which the unit
grants access in its three modes of operation. There are three user
levels:
Normal
A Normal user only has a Primary code and is only granted access
when the unit is in Normal or Bypass mode.
Secure
A Secure user must have a Primary and Secondary code
programmed; the two codes cannot be the same. The Secure
User can gain access when the unit is in any of its three modes of
operation. In Normal mode, the Secure user must use the Primary
