Reader Operation
AYC-E/Q60 Series Installation and Programming Manual 29
4.2.5 Selecting Rosslare Proximity Card Transmission
Format
The AYC-E/Q60 can read Rosslare proximity cards (125 kHz) and can
output Rosslare proximity card data as Wiegand 26-Bit, Clock & Data,
and Wiegand + PIN.
To select the Rosslare proximity card transmission format:
1. Enter Programming mode.
2. Press 2 to enter Menu 2.
The left LED turns red.
3. Enter one of the following codes:
1 – Wiegand 26-Bit
2 – Clock & Data
3 – Wiegand Card + PIN
You hear three beeps.
The system returns to Standby mode.
If an incorrect option is entered, the reader returns to Standby
mode and the keypad transmission format remains unchanged.
4.2.5.1 "Wiegand Card + PIN" Transmission Format
This unique mode is intended to let host controllers get card and
keypad data simultaneously. This option overrules the selected
Keypad Transmission Format and sends the keypad data as described
below.
After a card is presented to the unit, the program LED starts to flash
in green and indicates that the unit is waiting for the PIN code. If the
entry of 1- to 5-digit keypad PIN code is disturbed and a number key
or # is not pressed within 5 seconds, the keypad clears the card buffer
and the PIN code entry buffer, generates a medium length beep, and
is ready to receive a new card.
