Installation
AYC-E/Q60 Series Installation and Programming Manual 13
3. Installation
Installation of an RFID reader adjacent to metallic surfaces
might alter the reader’s specifications. To diminish this
interference, use a plastic spacer when mounting the reader.
3.1 Mounting the AYC-E60
Before starting, select the location to mount the unit. This location
should be at shoulder height.
1. For wall mounting, use the included mounting template as a
guide for drilling holes for mounting screws and wiring (Figure 1).
For US Gang Box mounting, no drilling is necessary.
Figure 1: Drilling and Mounting Template for AYC-E60
