Reader Operation
26 AYC-E/Q60 Series Installation and Programming Manual
If * is pressed during PIN code entry or a PIN code greater than
65,535 is entered, the keypad clears the PIN code entry buffer,
generates a beep and is ready to receive a new 5-digit keypad PIN
code.
If the entry of the 1- to 5-digit keypad PIN code is disrupted and a
number key or # is not pressed within 5 seconds, the keypad clears
the PIN code entry buffer, generates a medium length beep, and is
ready to receive a new 1- to 5-digit keypad PIN code:
(EP) FFFF FFFF AAAA AAAA AAAA AAAA (OP)
Where:
EP = Even parity for first 12 bits
OP = Odd parity for last 12 bits
F = 8-Bit Facility code
A = 16-Bit code generated from keypad
4.2.3.6 6 Keys BCD and Parity Bits, Wiegand 26-Bit
This option sends buffer of 6 keys, adds parity, and sends a 26-bit
BCD message. Each key is a four bit equivalent of the decimal
number.
The keypad PIN code must be 6 key presses in length. On the sixth
key press of the 6-digit PIN code, the data is sent across the Wiegand
Data lines as a BCD message.
If the entry of the 6-digit keypad PIN code is disrupted and a number
key or # is not pressed within 5 seconds, the keypad clears the PIN
code entry buffer, generates a medium length beep, and is ready to
receive a new 6-digit keypad PIN code:
(EP) AAAA BBBB CCCC DDDD EEEE FFFF (OP)

Rosslare AYC-E60B Specifications

General

Read Range	Up to 8 cm (3.15 in.)
Output Formats	Wiegand 26-Bit
Communication Interface	Wiegand
Interface	Wiegand
Operating Temperature	-31°C to +63°C (-25°F to +145°F)
Operating Humidity	0 to 95% (non-condensing)
Material	Polycarbonate
Audio/Visual Indication	Buzzer and Multicolor LED
Type	Proximity Card Reader
Temperature Range	-31°C to 63°C (-25°F to 145°F)
Compatibility	Compatible with standard access controllers
Humidity	0 to 95% (non-condensing)
Humidity Range	0% to 95% (non-condensing)
