INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 0
74-00-00
Page 2
January 01/2012
Overview
Ignition system
Fig. 1
Part Function
1 Resistance spark plug connector
2 Dual ignition coil
3 Ignition cable
4 FUSE BOX assy.
5 Electrical LINE A+B with connectors
6 Crankshaft position sensors
7 Stator assy.
8 Fly wheel
9ECU
