Rotax 912 i series Installation Manual

d05165.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 0
10-10-00
Page 4
January 01/2012
Graphic
Governor pivot point (A)
Fig. 1
1.3) Preservation and storage of the engine
General note The engine is preserved at BRP-Powertrain thus guaranteeing proper pro-
tection against corrosion damage for at least 24 months after the date of
delivery from BRP-Powertrain.
Warranty This warranty is subject to the following conditions:
- The engine must be stored in the GENUINE-ROTAX packing as sup-
plied by BRP-Powertrain.
- The covers on various openings must not be removed.
- The engine must be stored in a suitable place (at min. -40 °C/-40 °F
and max. +80 °C/176 °F).
- The flat bag (blue) surrounding the engine must not be damaged or
removed, as it protects the engine from corrosion and oxidation.
Storage If the engine is stored for a period longer than 12 months (not stored in the
GENUINE-ROTAX packing) then maintenance tasks must be carried out
every 3 months as per the currently valid Maintenance Manual, section
“Preservation of a new engine“.
1.4) Protective coverings
General note

WARNUNG
NOTICE
Protective coverings are only for use during transport
and engine installation. They must be removed before
the engine is operated.

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
