INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
75-00-00
Page 22
January 01/2014
Radiator
Weight: see chap. 72-00-00 section: 2.1)
Fig. 12
Cooling air duct Weight: see chap. 72-00-00 section: 2.1)
Fig. 13 09165
49 (1.93in.)
415 (16.34in.)
147,5
(5.81in.)
21
(0.83in.)
25 (1in.)
=150= (5.91in.)
25 (1in.)
= 168 =
(6.62in.)
136
(5.36in.)
21
(0.83in.)
27 (1.07in.)
43,5 (1.71in.)
25 (1in.)
4,1 (0.16in.)
34
(1.34in.)
M6 10 [4x]
09975
