d05786.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
76-00-00
Page 3
January 01/2014
Overview
Engine control
Fig. 1 08725
Part Function
1 Control unit assy. (ECU)
2 FUSE BOX assy.
3 Rectifier regulator A (black connector)
4 Rectifier regulator B (grey connector)
5 LANE A (X1)/ LANE B (X2) plug connection
6 Plug connection (X3)
