Rotax 912 i series Installation Manual

d05786.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 2
76-00-00
Page 15
January 01/2014
Graphic
Wiring HIC-Maintenance und Display
Fig. 6 08590
912 iS wiring harness
Airframe Ground
EMS ground
AWG 14 (2,50 mm²) AWG 16 (1,50 mm²) AWG 18 (1,00 mm²) AWG 20 (0,75 mm²)
Optional (not required)
1
6
9
5
Sicherungskasten / Fuse Box
Reglerplatte A
Regulator board A
Reglerplatte B
Regulator board B
ECU
1
6
9
5
Display AC manufacturer HIC A 4 CAN_GND_1_A (AWG 20) 5 CAN_LOW_1_A (AWG 20) 6 CAN_HIGH_1_A (AWG 20) HIC B 6 CAN_GND_1_B (AWG 20) 7 CAN_LOW_1_B (AWG 20) 8 CAN_HIGH_1_B (AWG 20)
C
A
N
_
G
N
D
_
1
_
A
C
A
N
_
L
O
W
_
1
_
A
C
A
N
_
H
I
G
H
_
1
_
A
C
A
N
_
G
N
D
_
1
_
B
C
A
N
_
L
O
W
_
1
_
B
C
A
N
_
H
I
G
H
_
1
_
B
HICA/B
Maintenance SUB D 9 pole HIC A Pin Connection 10 CAN_GND_2_A (AWG 20) 11 CAN_LOW_2_A (AWG 20) 12 CAN_HIGH_2_A (AWG 20) HIC B 14 CAN_GND_2_B (AWG 20) 15 CAN_LOW_2_B (AWG 20) 16 CAN_HIGH_2_B (AWG 20)
08590

Rotax 912 i series Specifications

General

Number of Cylinders	4
Max Power	100 hp (73.5 kW)
Max Power Output RPM	5800 rpm
Ignition System	Dual electronic ignition
Oil System	Dry sump, forced lubrication with separate oil tank
Reduction Gear Ratio	2.43:1
TBO	2000 hours
Engine Type	4-stroke, horizontally opposed
Displacement	1352 cm³
Bore x Stroke	84 mm x 61 mm
Max Torque	128 Nm
Fuel Type	Avgas 100LL or unleaded automotive gasoline
Fuel System	Electronic fuel injection
Cooling System	Liquid/air-cooled
