INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 0
79-00-00
Page 28
January 01/2012
Angular tube
Bent socket
Hose nipple with cap nut (straight nipple)
Angular tube (90°)
Outer dia. 13.2 mm (0.52 in.)
Slip-on length max. 21 mm (0.83 in.)
Tightening torque 22 Nm (16.23 ft.lb.) and LOCTITE 648
Bent socket (90°)
Outer dia. 12 mm (0.47 in.)
Slip-on length max. 24 mm (0.94 in.)
Tightening torque 25 Nm (18.44 ft.lb.)
Hose nipple with cap nut
Outer dia. 12 mm (0.47 in.)
Slip-on length max. 24 mm (0.94 in.)
Tightening torque 25 Nm (18.44 ft.lb.)
