Rotax 912 i series - Page 40

d05165.fm
INSTALLATION MANUAL
BRP-Powertrain
Effectivity: 912 i Series
Edition 1/Rev. 0
10-10-00
Page 10
January 01/2012
Attachment points
x-axis
mm/in
y-axis
mm/in
z-axis
mm/in
L1 -200.8/-7.90 -71.0/-2.80 -211.0/-8.31
R1 -200.8/-7.90 -71.0/-2.80 -211.0/-8.31
L2 -564.0/-22.20 105.0/4.13 -277.0/-10.91
R2 -564.0/-22.20 -105.0/-4.13 -277.0/-10.91
L3 -564.0/-22.20 105.0/4.13 -7.0/-0.28
R3 -564.0/-22.20 -105.0/-4.13 -7.0/-0.28
L4 -128.3/-5.05 87.0/3.43 0
L4 -128.3/-5.05 -87.0/-3.43 0
Attachment
points
Max. permissible force
(secure load) in (N) in.
x, y, and z axis
Max. permissible bending mo-
ment
(secure load) in (Nm) in.
x, y, and z axis
L1 5000/196.85 77/3.03
R1
L4 1900/74.80 39/1.54
R4
Attach-
ment
points
Max. permissi-
ble force
(secure load) in
(N) in.
x axis
Max. permissi-
ble bending mo-
ment
(secure load) in
(N) in.
y axis
Max. permissi-
ble bending mo-
ment
(secure load) in
(N) in.
z axis
Max. permissi-
ble bending mo-
ment
(secure load) in
(Nm) in.
x, y and z axis
L2 5000/196.85 2000/78.74 3000/118.11 100/3.94
R2
L3
R3
Attachment points Thread
Max. usable
Thread length
L1 M10 25 mm/0.98 in.
R1
L4 M10 16 mm/0.63 in.
R4
