RKHBH/X008AA
Indoor unit for air to water heat pump system
4PW50203-1A
Installation manual
29
TECHNICAL SPECIFICATIONS
General
Electrical specifications
Heating/cooling models (RKHBX) Heating only models (RKHBH)
Nominal capacity
• cooling
Refer to the Technical Data
• heating
Refer to the Technical Data
Dimensions H x W x D 922 x 502 x 361 922 x 502 x 361
Weight
• machine weight
50 kg 50 kg
• operation weight
65 kg 65 kg
Connections
•water inlet/outlet
G 1 (male) G 1 (male)
•water drain
hose nipple hose nipple
• refrigerant liquid side
Ø6.4 mm (1/4 inch) Ø6.4 mm (1/4 inch)
• refrigerant gas side
Ø15.9 mm (5/8 inch) Ø15.9 mm (5/8 inch)
Expansion vessel
•volume
10 l 10 l
• maximum working pressure (MWP)
3 bar 3 bar
Pump
• type
water cooled water cooled
•no. of speed
33
Sound pressure level
(a)
28 dBA 28 dBA
Internal water volume 5.5 l 5.5 l
Pressure relief valve water circuit 3 bar 3 bar
Operation range - water side
• heating
+25~+50°C +25~+50°C
• cooling
+5~+22°C —
Operation range - air side
• heating
–20~+25°C –20~+25°C
• cooling
+10~+43°C —
• domestic hot water by heat pump
–15~+35°C –15~+35°C
(a) At 1 m in front of the unit (free field condition)
Heating/cooling models (RKHBX) Heating only models (RKHBH)
Standard unit (power supply via outdoor unit)
•power supply
230 V 50 Hz 1P
• nominal running current
See outdoor unit installation manual
Backup heater
•power supply
See "Connection of the backup heater power supply" on page 13
• maximum running current
See "Connection of the backup heater power supply" on page 13
