Magnetic Amplifier Circuit Board 45072801 (Rev. E)
NOTE:
This components list is intended as a troubleshooting aid only. Rowe does not recommend
replacement of any magnetic amplifier circuit board components. Replacing components on this circuit
board may damage the magnetic head.
C601 Capacitor - Ceramic 50 VDC 5% 330 pF 70028837
C602 Capacitor - Tantalum 16 VDC 10% .1 µF 70025201
C603 Capacitor - Ceramic 50 VDC 5% .1 µF 70028966
C604 Capacitor - Tantalum 16 VDC 10% .1 µF 70025201
C605 Capacitor - Ceramic 50 VDC 5% 330 pF 70028837
C606 Capacitor - Tantalum 16 VDC 20% 6.8 µF 70025203
C607 Capacitor - Ceramic 50 VDC 5% .0047 µF 70025203
C608 Capacitor - Ceramic 50 VDC 5% .0047 µF 70025203
C609 Capacitor - Tantalum 16 VDC 10% .33 µF 70025202
C610 Capacitor - Tantalum 16 VDC 20% 6.8 µF 70025203
C611 Capacitor - Ceramic 50 VDC 5% .01 pF 70028941
C612 Capacitor - Ceramic 50 VDC 5% .01 pF 70028941
C613 Capacitor - Tantalum 16 VDC 10% .33 µF 70025202
C614 Capacitor - Tantalum 16 VDC 10% .1 µF 70025201
C615 Capacitor - Ceramic 50 VDC 5% 330 pF 70028837
C616 Capacitor - Tantalum 16 VDC 10% .1 µF 70025201
C617 Capacitor - Ceramic 50 VDC 5% .1 µF 70028966
C618 Capacitor - Ceramic 50 VDC 5% 330 pF 70028837
J601 Polarizing Wafer (90°) 4 Position 70074404
Q601 Transistor - PNP 70030106
Q602 Transistor - PNP 70030106
