BC-3500 Bill and Coin Changer
4-12 25238801
REJECT - NO MAG
Symptom:
Not enough magnetic signal from the Mag. Amp.
This is a reject message.
The bill was rejected because no signals came from the Mag. Amp.
The bill may have been inserted upside down.
If bills are frequently rejected for this message:
Corrective Action:
1. Check for intermittent connections in the Mag. Amp. harness or the White/Brown, White/Green wires from
the transport to the CCC (P4 - Pins 2 and 5).
2. Check the bill pressure rollers in the transport for proper spring pressure.
3. Check the surface of the Mag. head for dirt buildup or foreign material.
4. If all of the preceding checks are OK, replace the Mag. Amp.
5. If the problem still exists, replace the CCC.
If a bill is left in the transport for five seconds, the bill changer will go into SELF-CLEAR.
