Section 2: Installation & Programming
25238801 2-21
Accessing the ANTI-PULLBACK Menu
1. Move the PROGRAMMING/NORMAL switch on the bill changer from the NORMAL operation mode to the
PROGRAMMING position.
2. Press the FUNCTION-ERROR RESET button twice. The display should show “PROGRAMMING ——”.
3. Press the ^ button until the display shows “
PROGRAMMING 11—”, the press the VALUE button once.
4. Press the ^ button until the display shows “
PROGRAMMING 1130”.
5. Press the VALUE button once. The ANTI-PULLBACK menu is now active.
Navigating the ANTI-PULLBACK Menu
1. When first entering the ANTI-PULLBACK menu, the display will show “PULLBK SHTDN OFF”. This means
that the computer is not monitoring the transport motor for unexpected movement..
2. Pressing the ^ button will cause the display to show “PULLBK SHTDN 1”. This means that the computer will
now be watching for unexpected transport motor movement, and will take the changer OUT OF SERVICE for
1 minute should any such activity occur.
3. Using the
and
buttons, set the number of minutes of shutdown time desired. The maximum number of
minutes can be set at 98; if you increment once more using the ^ button, “INF” will be displayed indicating that
if an incident is detected, the changer will stay OUT OF SERVICE until in is manually reset with The FUNCTION-
ERROR RESET button.
MISCELLANEOUS
The BC-3500 was designed to be simple and easy to troubleshoot. Please take time to study the operation of the
machine and to study the explanations of the various status messages.
The following is a list of incidental characteristics that may be of interest to the operator and service person:
1. Both the coin acceptor and the bill acceptor are blocked out during the dispense and replenish cycle. Also,
the coin acceptor is locked out during the bill validation cycle as soon as the VI cell is covered. The coin
acceptor is locked out whenever no coins are programmed to be accepted.
2. The +5 VDC voltage from the power supply does not control the CCC board. It is used to provide voltage
to LED’s (dispenser, transport, OUT OF SERVICE light), and the solid-state coin switch assembly. The
computer board is powered primarily by the +8 VDC voltage from the power supply. It has its own +5
VDC regulator.
3. The BILL RETURN switch is disabled during the latter portion of the validation cycle and the entire dispense
and replenish cycles.
