Section 4: Troubleshooting
25238801 4-13
REJECT - LATE VF
Symptom:
The flipper cell did not cover.
This is a reject message.
The bill was rejected because the VF cell was not covered soon enough after the VT cell was covered.
The bill is possibly torn at its leading edge.
An object is possibly hung-up or jammed in the track.
If bills are frequently rejected with this message:
Corrective Action:
1. Check for tight, binding, or sticky flipper operation.
2. Check for an intermittent open circuit in the wiring to the VF cell from the CCC (P4 - Pin 7).
3. Check the rear portion of the transport track for any condition that would cause a bill to slow down or hang
up (soft drink residue, catsup, burrs in the track, etc.).
4. The drive belts of the transport may be broken or slipping. Check them and replace the drive belts if necessary.
5. If none of the preceding steps find the problem, replace the CCC.
If a bill is left in the transport for five seconds, the bill changer will go into SELF-CLEAR.
