Section 4: Troubleshooting
25238801 4-7
REJECT - SHORT VF
Symptom:
Flipper cell covered for too short a time.
This is a reject message.
The bill was rejected because the flipper cell was uncovered too soon and the CCC recognized this as a non-valid
validation sequence. If bills are rejected frequently with this message:
Corrective Action:
1. Check for small pieces of paper or other foreign objects in the track.
2. The flipper may be binding or hanging-up on the back rollers. Check for flash or burrs on the flipper and back
rollers.
3. The flipper cell may be giving an intermittent signal. Check the cell for proper switching. If the cell is OK, check
the wiring from the transport to the CCC for a possible ground to the chassis or an open to the CCC (P4 -
Pin 7).
4. If all of the preceding checks are OK, replace the CCC.
If the bill is left in the transport for five seconds, the machine will go into SELF-CLEAR.
