Section 2: Installation & Programming
25238801 2-7
SETTING UP THE BC-3500
These steps should be followed to set up the BC-3500 to your requirements. If you do not follow these steps, the
BC-3500 will remain all or partially programmed to the factory settings.
Quick Setup for a BC-3500 Dispensing Quarters Only
1. Place the programming switch (next to the display on the central control computer) in the up position
(programming mode). The display will show “TEMP COUNTERS”.
2. Press the
FUNCTION button until the display reads “MC PAYOUT” either “ON” or “OFF”.
3. Press either of the two far right buttons (
or
) until the display shows “MC PAYOUT ON”.
4. Press the FUNCTION button once and the display will show “HOP VAL” along with three of the following: “- -”,
“T1”, “T2”, “T3”, “5”, “10”, “25”, “50”, “$1”.
5. Press the VALUE button until the display shows “HOP VAL 25 25 25”.
6. Press the FUNCTION button once and the display will show “ACCEPT $1” with either a “YES” or a “NO”.
7. Use either the
or
button to turn the $1 acceptance to “YES” or “NO”. (YES to accept $1 bills. NO to not
accept $1 bills.)
8. Next press the VALUE button to go through all other denominations you wish to have the changer accept or
not accept, and use either the
or
button to turn each one to “YES” or “NO”. (You will return to the “ACCEPT
$1” statement when you have gone through all denominations.)
9. Press the FUNCTION button once and the display will show the lowest denominations set to “YES” in Step 8,
and “PAYS __ MC MC”.
10. Press either the
or
button until the display shows “PAYS (XX) MC MC”, where “XX” equals the number to
equal the denomination shown (i.e., 4 for a $1, 20 for a $5, etc.). Press the VALUE button to step through
each denomination you have set to “YES” for acceptance, and set the proper payout for each. NOTE: $10
or $20 may show 2X some number which will equal the correct amount.
NOTE: Make sure each denomination set to “YES” for acceptance has the correct payout amount or the
message “INCORRECT PAYOUT” will be displayed.
11. Press the FUNCTION button once and the display will show “STACKER MODE SEP” or “ALT” (SEParate or
ALTernate).
12. Push either the
or
button to set the stacker to the mode you desire. If set to “ALT”, the changer will alternately
stack each bill accepted to the upper bill box first, and then to the lower bill box regardless of the denomination
accepted. If set to “SEP”, each denomination accepted can be assigned to be stacked in either the upper or
lower bill box.
