Section 4: Troubleshooting
25238801 4-9
REJECT - TIMEOUT
Symptom:
Inlet cell was never uncovered.
This is a reject message.
The bill was rejected because the VI cell never uncovered. The CCC recognized this as a non-valid validation
sequence. Take the following corrective action if bills are rejected frequently with this code.
Corrective Action:
1. Check for small pieces of paper or other foreign objects in the track.
2. The VI cell may be giving an intermittent signal. Check the VI cell for proper switching.
3. If the cell is OK, check the wiring from the VI cell to the CCC (P4 - Pin 14) for a possible short to the chassis.
4. The +5VDC supply to the LEDs may be low; check the voltage. If it is low, replace the VR801 regulator on
the power supply board, which is inside the power control center.
5. If all of the preceding checks are OK, replace the CCC.
If a bill is left in the transport for five seconds, the bill changer will go into SELF-CLEAR.
