Section 3: Routine Service
25238801 3-5
3. Using the Nylon hopper cleaning brush supplied with each machine, remove all dirt from the angular sides
and flat surfaces of the serpentine coin path as shown in Figure 3-4A.
4. Reassemble the hopper (when finished cleaning) by replacing the back chain plate assembly and
starting
all screws removed. Once all screws have been started, they may then be tightened. The screws must
be tightened in sequence as shown in Figure 3-4C.
5. Install the hopper in the bill changer and make a test vend to check for proper hopper operation.
WARNING:
Chain lubrication is not normally required or recommended. Do not use detergents to
clean the hopper. The hopper has been factory lubricated and detergent cleaners may
destroy this lubrication.
Figure 3-4C
