BC-3500 Bill and Coin Changer
4-18 25238801
REJECT - BILL (H)
Symptom:
The bill failed validation because the information from Mag Head 2 was incorrect.
Corrective Action:
1. Check the White/Green wire from the transport for an Open/Short to the CCC (P4 - Pin 5).
2. Replace the mag amp/transport.
3. Replace the CCC.
REJECT - BILL (I, J, K, M, or S)
Symptom:
Bills rejected with any of these codes are failing a number of interrelated magnetic tests.
Corrective Action:
1. Replace the transport
2. Replace the CCC.
REJECT - BILL (L)
Symptom:
The bill failed validation because there was insufficient mag signal from certain points on the bill.
Corrective Action:
1. Replace the transport
2. Replace the CCC.
REJECT - BILL (P)
Symptom:
The bill failed validation due to incorrect mag information from either mag head.
1. Replace the Mag. amp/transport
2. Replace the CCC.
