RT Systems TM3 - Power, Network, and Antenna Connections

10
power cord, network cable and GSM antenna connections
symbol description
C
Caution: Before you energise the appliance, review the electrical specications to avoid overloading
the circuit.
C
Caution: Make sure you properly ground the appliance by plugging the power cord directly into a wall outlet
or by verifying the ground path if using a power strip.
N
Note: The power cord provided is to be used only with the TM3 Monitoring Unit.
N
Note: Only use the GSM antenna provided with the unit.
1. Connect the supplied power cord to the AC Line Inlet of the unit.
2. Secure the power cord to the power cord retainer bracket using the tie wraps.
3. Connect the supplied network cable to the 10/100 Base-T Network Port on the unit.
4. Plug the power cord into a power source.
5. Connect the GSM antenna to the unit.
