52
item description
A Power Inlet Fuse, 2A, 250V, 5x20 Glass Fuse
B Battery Fuse, 2A, 250V
C Power Supply
D 12V, 2.3AH Sealed Lead Acid Battery, PN PS2.3-12
E 3V Coin Cell Battery, CR2032
F SD Card
G GSM Sim Card
trouble shooting
problem cause/correction
Unit does not
complete initialization
n Check that SD Card is installed and that default or specic conguration data is on the SD Card. Copy
default conguration les from CD if not on SD Card.
n Check that the Sim Card is installed in the GSM Board.
n Check that the Sim Card PIN is congured correctly.
GSM Card Failure
during Self Test
n Check that the GSM number is correct on the GSM Conguration Page. The unit sends an SMS to itself
during self test and if the number is incorrect the SMS is not received.
The unit does not
turn on
n Check the fuse on the inlet AC adapter and replace if fused.
Unit switches off
during mains failure
n Check Battery Fuse and replace if fused.
n Check that backup battery is charged and healthy.
No SMS is sent when
alarm is activated
n Check that the GSM number is correct on the GSM Conguration Page. Number must be in
international format.
n Check that the SMSC number is correct on the GSM Configuration Page. Number must be in international
format (check with your local cellular service provider for SMSC number)
n Check that the PIN number is correct on the GSM Configuration Page. Follow steps on page 16 if PIN
on SIM is not activated.
n Check that the PUK number is correct on the GSM Configuration Page.
n Check that SMS tick box is ticked in Dry Contacts Conguration Page.
