RDC6563F Standalone Fiber Cutting Control System User Manual V2.0 25
SHENZHEN RUIDA TECHNOLOGY CO., LTD
PIN12
GND
GND
PIN13
GND
GND
PIN14
+24V
+24V power（output）
controller+5V power
output，Current output
capability more than
500mA
PIN15
CLR
Servo alarm clear signal
(output)
PIN16
OS
Servo zero speed clamp
signal (output)
PIN17
A+
Encoder A phase signal
differential positive port
PIN18
B+
Encoder B phase signal
differential positive port
PIN19
LMT+
Lower limit switch input
PIN20
GND
GND
PIN21
GND
GND
PIN22
—
NC
PIN23
—
NC
PIN24
ANALOG _OUT
0-10V Analog voltage
output
For controlling proportional
valve
PIN25
GND
GND
Important:
 Some servo drives only support pulse control mode, but
not speed control mode. Please select the servo drive
that supports speed control mode correctly.
 Z-axis servo drive only supports Panasonic A5 series,
Sanyo R series, Yaskawa ∑ series, Schneider 23D, Fuji A5
series servo drives .
